5g Home Router support Router/5G, support VPN, IPv6,Guest Wi-Fi, Parental control, SMS, Phone book, Guest network, WPA3
KS-5G-XM520P is an high speed 11ax Wi-Fi6 standard 5G router with SIM card slot, with Unisoc chipset, dual band, maximum 2.2Gbps in 5G speed, plug and play, satisfied with growing-up high speed mobile connections requirements and provides the fast speed beyond your imagination.
Main Features:
Multiple Mobile Network Compatible
Support 5G NSA+SA, 4G LTE-TDD+LTE-FDD, 3G WCDMA mobile networks;
Compatible global bands, support all SIM cards
Dual band wireless signal for more users
Comply the latest WiFi6 standard, dual band with 1800Mbps high speed. MU-MIMO, DL/UL-OFDMA modulation, 5G prior, allow 50+ users access into this router, and easy to make all users automatically selects the best connection, to keep the running ultra-fast.
High speed 5G Network, plug and play
Compatible with NSA/SA dual-mode, more than 400Mbps real 5G throughput, suits to all network types all over the world, plug and play, let's enjoy the ultra-fast broadband connection at any places
VPN remote control
Support L2TP and PPTP VPN client, it allow the communication between VPN server.
More features such as eSIM, SMS, Phone book, IPv6, PoE output, Mesh
Detailed Photos
Product Parameters
| Hardware Spec: |
| Model |
KS-5G-XM520 |
| WiFi Standard |
IEEE 802.11b/g/n/ac/ax |
| CPU |
MT7621DAT+MT7905N+MT7975DN |
| Flash |
16MB |
| Memory |
256MB DDR3 |
| Frequency |
2.4G: 2400 - 2484MHz |
| 5.8G: 5150 - 5850MHz |
| Data Rate |
600Mbps @ 2.4GHz; 1200Mbps @5.8GHz |
| RF Power |
≤ 21dBm |
| Access Users |
100+ Clients |
| Interface |
2* 10/100/1000Mbps LAN
(Optional: 1*RJ11 port optional to support VoLTE, 1*10/10/100/1000Mbps LAN port) |
| 1*10/100/1000Mbps WAN |
| Button |
Reset button |
| WPS Button |
| SIM |
1*SIM card slot for 5G SIM card |
| Switch |
LED Switch |
| LED Indicator |
4G |
| 5G |
| WIFI |
| Power |
| ETH |
| Antenna |
Build in 5dBi MIMO Antenna |
| Power Consumption |
<20W |
| DC Power Supply |
48V/1A |
| Working temperature |
Working Temperature:-20ºC~55ºC |
| Storage temperature: -30ºC~70ºC |
| Humidity |
5%~95% |
| Dimensions |
108mmX108mmX216mm |
| 4G/5G Speed |
| 5G Chipset |
Unisoc UDX710 (Asia/Middle East) |
| 4G/5G Band |
5G: NSA:n41/78/79; SA:n1/28/41/77/78/79
LTE-FDD: B1/B2/B3/B5/B7/B8/B20/B28;
LTE-FDD: B34/B38/B39/B40/B41; WCDMA:B1/B2/B5/B8 |
| 4G/5G Speed |
NSA: Max. 2.2Gbps(DL)/575Mbps(UL);
SA: Max. 2Gbps(DL)/1Gbps(UL);
LTE: 600Mbps(DL)/150Mbps(UL);
UMTS: 42Mbps(DL)/11Mbps(UL); |
| Firmware Features |
| Operation mode |
Router/5G |
| Multiple Functions |
2.4G SSID and 5.8G SSID combined together, support 5.8G first always |
| Support SSID hidden |
| Support SMS, Phone book, QXDM tool |
| Support DDNS |
| Support Guest Network and Parental Control |
| VPN |
VPN Client (L2TP PPTP) |
| Security |
Open, WPA, WPA2PSK_TKIPAES, WAP2_EAP, WPA3 |
| TR069 |
Can develop it |
| IP Protocol |
IPv4/IPv6 |
| Device Management |
GUI web management |
| Support firmware back-up, restore, reset, upgrade |
Packing List
|
KS-5G-XM520*1
Power adapter×1(12V2A)
Cat 6 LAN Cable×1(1 meter)
User Manual×1
|
Packaging & Shipping
12PCS/CTN
Weight: 9.6KGS/CTN
CTN size: 59*50*23cm
After Sales Service
2 years warranty
FAQ
Q1. 5G bands:
A: Right now it can support global bands or locally bands;
We suggest to select the one which can meet with local bands as samples;
In the mass orders, we can customize the 5G bands if QTY large to save cost and increase the quantity;
Q2. OEM & ODM service
A: OEM: provide your LOGO to us, we can add your LOGO on the product, firmware and package;
Content will be limited by MOQ;
ODM: we can provide PCBA, housing and firmware ODM service:
PCBA: 2~3 month to finish it;
Housing: 2 month after finish the PCBA;
Firmware: we can provide the open source driver for customer to develop their firmware;
We can provide DTS files if want;
And we can provide technical support in customer firmware development.
Q3. If support out of China production:
A. Yes, this is developed by our engineers, we can support SKD and CKD;
We can provide the SOP of assemble and finished product testing;
But for the CKD, firstly you can do the RF calibration, 2nd you should have engineer to debug the problem;
We can provide SOP or all documents, and we can send engineers to provide technical support, but will be costly.
